Automotive Wires and Cables

Our PVC-insulated copper automotive wires are engineered for durability, flexibility, and reliable performance in automotive wiring harness applications.

These products are certified under international automotive standards, including:

  • ISO 6722-1
  • JASO D625-3
  • PSA (B251 1110)
  • DIN 72551



They are IATF-approved and widely used in passenger vehicles, trucks, and heavy-duty equipment for power distribution, signal transmission, and control systems.


Automotive Wires and Cables
  • FLRY-A
  • avs
  • P2S
  • P3S
  • B2
  • pvc
  • Heat - resistant PVC insulated wires
  • heat
  • heat
  • pvc
  • pvc thin
FLRY-A
  • Standard : ISO 6722-1
  • Conductor : High Conductivity Drawn Copper
  • Isolation : PVC [classe A]
  • Temperature : 105 C [Max operating Temperature]
  • Voltage : 30 V [AC] & 60 V [DC].
  • Size mm²: from 0.35 mm² to 6 mm²

FLRY-B
  • Standard : ISO 6722-1
  • Conductor : High Conductivity Drawn Copper
  • Insulation : PVC [class B]
  • Temperature : 105 C [Max operating Temperature]
  • Voltage : 30 V [AC] & 60 V [DC].
  • Size mm²: from 0.35 mm² to 6 mm²

Sed Porttitor Lectus Nibh

Curabitur non nulla sit amet nisl tempus convallis quis ac lectus...

Nulla quis lorem ut libero malesuada feugiat...

  • Default feature
• Norme : JASO_D625-3
• Conducteur : cuivre étiré à haute conductivité
• Isolation : PVC
• Température : 80 °C [Température de fonctionnement maximale]
• Tension : 30 V [AC] et 60 V [DC].
Taille mm² : 0,3 mm², 5 mm², 8 mm²

AVSS
• Norme : JASO_D625-3
•Conducteur : Cuivre étiré à haute conductivité
• Isolation : PVC
• Température : 80 °C [Température de fonctionnement maximale]
• Tension : 30 V [AC] et 60 V [DC].
• Taille mm² : 0,3 mm² – 1,25 mm², 0,75 mm² F, 2 mm² F

Sed Porttitor Lectus Nibh

Curabitur non nulla sit amet nisl tempus convallis quis ac lectus...

Nulla quis lorem ut libero malesuada feugiat...

  • Default feature
  • Standard : ISO 6722-1
  • Conductor : High Conductivity Drawn Copper
  • Isolation : PVC
  • Temperature : 105 C [Max operating Temperature]
  • Voltage : 30 V [AC] & 60 V [DC].
  • Taille mm² : 0,35 mm² – 6  mm²

Sed Porttitor Lectus Nibh

Curabitur non nulla sit amet nisl tempus convallis quis ac lectus...

Nulla quis lorem ut libero malesuada feugiat...

  • Default feature
  • Standard : ISO 6722-1
  • Conductor : High Conductivity Drawn Copper
  • Isolation : PVC
  • Temperature : 120 C [Max operating Temperature]
  • Voltage : 30 V [AC] & 60 V [DC].
  • Taille mm² : 0,35 mm² – 20 mm²

Sed Porttitor Lectus Nibh

Curabitur non nulla sit amet nisl tempus convallis quis ac lectus...

Nulla quis lorem ut libero malesuada feugiat...

  • Default feature
  • Standard : ISO 6722-1 & PSA (B251 1110)
  • Conductor : High Conductivity Drawn Copper
  • Insulation : PVC [class B]
  • Temperature : 105 C [Max operating Temperature]
  • Voltage : 30 V [AC] & 60 V [DC].
  • Size mm² : from 0.35 mm² to 6 mm²

Sed Porttitor Lectus Nibh

Curabitur non nulla sit amet nisl tempus convallis quis ac lectus...

Nulla quis lorem ut libero malesuada feugiat...

  • Default feature
  • Standard : ISO 6722-1
  • Conductor : Plain / tinned annealed copper
  • Isolation : PVC [classe A]
  • Température : 85 °C [Max operating temperature]
  • Size mm²: from 0.5 mm² to 6 mm²

Sed Porttitor Lectus Nibh

Curabitur non nulla sit amet nisl tempus convallis quis ac lectus...

Nulla quis lorem ut libero malesuada feugiat...

  • Default feature
  • Standard : ISO 6722-1
  • Conductor : Plain / tinned annealed copper
  • Insulation : Heat resistant PVC [Class B]
  • Température : 100 °C [max operating temperature]
  • Size mm²: from 0.5 mm² to 6 mm²



  • Standard : ISO 6722-1
  • Conductor : Plain / tinned annealed copper
  • Insulation : Heat resistant PVC [Class B]
  • Température : 100 °C [max operating temperature]
  • Size mm²: from 0.5 mm² to 6 mm²




Sed Porttitor Lectus Nibh

Curabitur non nulla sit amet nisl tempus convallis quis ac lectus...

Nulla quis lorem ut libero malesuada feugiat...

  • Default feature
  • Standard : ISO 6722-1
  • Conductor : Plain / tinned annealed copper
  • Insulation : Heat resistant PVC [Class B]  (Hot pressure resistance test at 120 °C)
  • Temperature : 100C [Max operating Temperature]
  • Size mm²: from 0.5 mm² to 6 mm²

Sed Porttitor Lectus Nibh

Curabitur non nulla sit amet nisl tempus convallis quis ac lectus...

Nulla quis lorem ut libero malesuada feugiat...

  • Default feature

Concentric PVC insulated conductors

  • Standard: DIN 72551.
  • Conductor: Concentric stranded copper conductor based on DIN 72551, part 6, type A.
  • Insulation: PVC (polyvinyl chloride) based on DIN 72551, part 5.
  • Temperature: 105°C [Max operating Temperature]
  • Size: from 0.35²to 2.5 mm²



 PVC thin insulated wires



  • Standard: DIN 72551.
  • Conductor: Concentric stranded copper conductor based on DIN 72551, part 6, type A.
  • Insulation: PVC (polyvinyl chloride) based on DIN 72551, part 5.
  • Temperature: 105°C [Max operating temperature]
  • Size mm²: from 0.35 mm² to 2.5 mm²



Sed Porttitor Lectus Nibh

Curabitur non nulla sit amet nisl tempus convallis quis ac lectus...

Nulla quis lorem ut libero malesuada feugiat...

  • Default feature

  • Standard: DIN 72551.

  • Conductor: Concentric stranded copper conductor based on DIN 72551, part 6, type A.

  • Insulation: PVC (polyvinyl chloride) based on DIN 72551, part 5.

  • Temperature: 105°C [Max operating temperature]

  • Size mm²: from 0.35 mm² to 2.5 mm²
